Fully-automatic aseptic liquid packing machine(Hereinafter called
packing machine)is a special equipment to pack the liquid which in the aseptic space,and was
processed UHT(ultra high temperature)treatment. This kind of
packing machine is widely used for the soft packing of milk,soy
milk,juice,mineral water, soy sauce, vinegar,etc.
1,Processing way. The packing machine will do as following during
packing the liquid,open the film rolls,automatically
sterilization,bag forming,quantitive filling,automatically
counting, date printing,sealing,cutting etc. All the process
completed in a ultra cleaning and enclosed space,and is control by
PLC.
2,Structure. The packing machine is constituted by mainbody ,pneumatic mechanism,rack,film bag sterilization,thefilm bag forming ,quantity filling ,date printing,sealing,cutting,CIP backwash PLC touch screensystem etc.
Serial number | project name | Technical parameters (performance, parameters) | Remarks |
1 | Production capacity | 2 tons/hour | |
2 | Filling capacity | 100ml-1000ml/bag | |
3 | Filling temperature | 2℃~95℃ | |
4 | Filling accuracy | ±1.5% | |
5 | Packing speed | 8000 bags per hour (250ml/bag-8000 bags/hour 1000ml/bag-3600 bag/hour) | |
6 | Sealing form | side seals | |
7 | Number of filling heads | 2 | |
8 | Packaging Type | Package width: 320mm±1.5mm | |
9 | control mode | PLC, touch screen | |
10 | Detection and alarm | Film missing and colourless band alarm and stop | |
11 | Working pressure of compressed air | 0.4MPa~0.7MPa | |
12 | Air flow rate | 1080 m3/h | |
13 | Purification degree of gas source | Class 100 (US federal standard 209E) | |
14 | air consumption | 0.1M3/min | |
15 | Power Supply and Power | 380V 50Hz 4KW | |
16 | Cleaning method | CIP in-situ cleaning | |
17 | Dimensions (length, width, height) | 2100×1080×3060 | |
18 | weight | 1200KG | |
1.Provide for equipment inspection certificate and manual, to ensure that
users properly install and use.
2.Equipment to reach the destination, the company will send
engineers to guide installation and
commissioning and customer training until satisfied.
3. The warranty period will be free to customers wearing
accessories, after one year warranty period, our
company to provide parts at cost.
4.we provide lifelong maintenance service, including if necessary,
to send engineers to the customer at the service.
